CMOS LOW DROPOUT LINEAR REGULATOR

Part NO.	Vin	Vout	Iout(Typ.)	Quiescent Current	Accuracy	Enable	Typical Feature	Packages	PDF
CE6200A/B	1.8~6.0V	1.0~5.0V	500mA	50μA	±2%/±1%	B:√	High PSRR(75dB@1kHz), Low Noise	SOT23-3/5, SOT-353(SC70-5), SOT89-3/5, DFN1*1-4, SOT-343(SC-82)	下載
CE6204A/B	1.8~6.0V	0.85~5.0V	500mA	45μA	±2%/±1%	B:√	High PSRR,Low Noise,with OTP	SOT23-3/5,SOT-353(SC70-5),SOT89-3/5	下載
CE6205A/B	1.8~6.0V	1.05~5.0V	500mA	50μA	±2%/±1%	B:√	High PSRR, Low Noise	SOT23-3/5, SOT-353(SC70-5), SOT89-3/5	下載
CE6210A/B	2.0~6.0V	1.1~5.0V	1000mA	80μA	±2%/±1%	B:√	High Speed, High PSRR	SOT23-5, SOT89-3/5, SOT-223	下載
CE6218E	2.0~6.0V	0.9~5.0V	300mA	5μA	±2%/±1%	√		SOT23-5,SOT89-5	下載
CE6219P	2.0~6.0V	0.9~5.0V	300mA	5μA	±2%/±1%			SOT23-3/5,SOT89-3,TO-92	下載
CE6230A/B	2.0~7.0V	1.2~5.0V	500mA	5μA	±2%/±1%	B:√	High PSRR@Low Current Consumption	SOT23-3/5,SOT-353(SC70-5),SOT89-3,DFN1*1-4, SOT-343(SC-82)	下載
CE6206A/B	2.0~7.0V	1.2~5.0V	300mA	5μA	±2%/±1%	B:√	High PSRR@Low Current Consumption	SOT23-3/5,SOT-353(SC70-5),SOT89-3, DFN1*1-4	下載
CE6232A/B	1.8~8.0V	1.2~5.0V	500mA	0.8μA	±2%/±1%	B:√	High PSRR & Low Noise@Ultral Low Current Consumption	SOT23-3/5,SOT89-3,TO-92,DFN1*1-4	下載
CE6233A/B	1.8~6.0V	1.0~5.0V	300mA	0.8μA	±2%/±1%	B:√	High PSRR@Low Current Consumption	SOT23-3/5,SOT89-3,TO-92,DFN1*1-4	下載
CE6260A/B	2.0~6.0V	0.9~5.0V	500mA	5μA	±2%/±1%	B:√		SOT23-3/5, SOT89-3/5	下載
CE6275A	2.0~30V	2.8~5.0V	150mA	2.5μA	±2%/±1%		High Voltage Input	SOT89-3, SOT23-3/5, TO-92	下載
CE6301A/B	2.5~18V	1.2~5.0V	300mA	2.0μA	±2%/±1%	B:√	High PSRR & Low Noise@ Low Current Consumption	SOT89-3/5, SOT23-3/5, TO-92	下載
CE6311A/B	2.5~18V	1.2~5.0V	500mA	2.5μA	±2%/±1%	B:√	High PSRR & Low Noise@ Low Current Consumption	SOT89-3/5, SOT23-3/5, TO-92	下載
CE6303A/B	2.5~28V	1.2~12.0V	300mA	1.8μA	±2%/±1%	B:√	High PSRR & Low Noise@ Low Current Consumption	SOT89-3/5,SOT23-3/5,TO-92	下載
CE6375A	2.5~36V	1.8~12V	250mA	2μA	±2%/±1%		High PSRR & Low Noise@ Low Current Consumption	SOT89-3, SOT23-3/5, TO-92,SOP8-PP	下載
CE6300	1.8~7.0V	0.6~5.5V	500mA	45μA	±2%	√	Adjustable Output, High PSRR(70dB@1kHz), Low Noise	SOT23-5/6, SOT-353(SC70-5), DFN2*2-6	下載
CE6601A/B	2.5~60V	1.2~12V	150mA	3μA	±2%/±1%	B:√	High Voltage Input	SOT89-3/5,SOT23-3/5,SOT223,TO-92	下載
CE6321A/B	2.5~18V	1.2~5.0V	1000mA	2.5μA	±2%/±1%	B:√	High PSRR & Low Noise@ Low Current Consumption	SOT89-3/5, SOT23-3/5, SOP8-PP	下載
